Auxiliary Brake and Accessories

Friction Disc Core 513667

Name Part No. Part No. Part No. Part No. Name Part No. Part No. Part No. Part No. Mounting Flange Sub Assembly. 513348-01 513348-01 513348-01 513348-01 Mounting Flange Sub Assembly. 513348-01 513348-01 513348-01 513348-01 Mounting Flange 513337 513337 513337 513337 Mounting Flange 513337 5...


Whatsapp:

Email:
jnkx168@163.com

      

Online Consultation

describe

mark

Name	Part No.	Part No.	Part No.	Part No.	Name	Part No.	Part No.	Part No.	Part No.
Mounting Flange Sub Assembly.	513348-01	513348-01	513348-01	513348-01	Mounting Flange Sub Assembly.	513348-01	513348-01	513348-01	513348-01
Mounting Flange	513337	513337	513337	513337	Mounting Flange	513337	513337	513337	513337
Wear Plate	508459	508459	508459	508459	Wear Plate	508459	508459	508459	508459
Stud	000245*0069	000245*0069	000245*0069	000245*0069	Stud	000245*0069	000245*0069	000245*0069	000245*0069
Friction Disc	508725	508725	508725	508725	Friction Disc	508725	508725	508725	508725
Friction Disc Core	510745	510745	510745	510745	Friction Disc Core	510745	510745	510745	510745
Clamp Tube	306542-05	306542-20	306542-23	306542-24	Clamp Tube	306542-05	306542-20	306542-23	306542-24
Pressure Plate Sub Assembly.	513348-03	513348-03	513348-03	513348-03	Pressure Plate Sub Assembly.	513348-03	513348-03	513348-03	513348-03
Pressure Plate	513345	513345	513345	513345	Pressure Plate	513345	513345	513345	513345
Flat Washer	000153*0641	000153*0641	000153*0641	000153*0641	Flat Washer	000153*0641	000153*0641	000153*0641	000153*0641
Locknut	000110*0073	000110*0073	000110*0073	000110*0073	Locknut	000110*0073	000110*0073	000110*0073	000110*0073
Cylinder	513264	513264	513264	513264	Cylinder	513264	513264	513264	513264
Lip Seal	000402*0023	000402*0023	000402*0023	000402*0023	Lip Seal	000402*0023	000402*0023	000402*0023	000402*0023
Lip Seal	000402*0024	000402*0024	000402*0024	000402*0024	Lip Seal	000402*0024	000402*0024	000402*0024	000402*0024
Gear	411672	410970	412433	413195	Gear	411672	410970	412433	413195
Wear Spacer	N/A	308396	308396	308396	Wear Spacer	N/A	308396	308396	308396
Reaction Plate Sub Assembly.	N/A	513348-02	513348-02	513348-02	Reaction Plate Sub Assembly.	N/A	513348-02	513348-02	513348-02
Reaction Plate	N/A	513343	513343	513343	Reaction Plate	N/A	513343	513343	513343
Pistion	513317	513317	513317	513317	Pistion	513317	513317	513317	513317
Release Spring	416751-02	416751-02	416751-02	416751-02	Release Spring	416751-02	416751-02	416751-02	416751-02
Inner Support Ring	413107	413107	413107	413107	Inner Support Ring	413107	413107	413107	413107
Outer Support Ring	413108	413108	413108	413108	Outer Support Ring	413108	413108	413108	413108
Flat Head Screw	000294*407	000294*407	000294*407	000294*407	Flat Head Screw	000294*407	000294*407	000294*407	000294*407
Pipe Plug	000077*0021	000077*0021	000077*0021	000077*0021	Pipe Plug	000077*0021	000077*0021	000077*0021	000077*0021
Name	Part No.	Part No.	Part No.	Part No.	Name	Part No.	Part No.	Part No.	Part No.
Mounting Flange Sub Assembly	513985-01	513985-01	513985-01	513985-01	Mounting Flange Sub Assembly	513985-01	513985-01	513985-01	513985-01
Mounting Flange	513986	513986	513986	513986	Mounting Flange	513986	513986	513986	513986
Wear Plate	416527	416527	416527	416527	Wear Plate	416527	416527	416527	416527
Stud	307111-04	307111-10	307111-05	307111-07	Stud	307111-04	307111-10	307111-05	307111-07
Friction Block Sub Assembly	513990	513990	513990	513990	Friction Block Sub Assembly	513990	513990	513990	513990
Friction Block	513658	513658	513658	513658	Friction Block	513658	513658	513658	513658
Friction Disc Core	513667	513667	513667	513667	Friction Disc Core	513667	513667	513667	513667
Clamp Tube	308204-07	513985-03	308204-04	308204-05	Clamp Tube	308204-07	513985-03	308204-04	308204-05
Pressure Plate Sub Assembly	513985-03	513985-03	513985-03	513985-03	Pressure Plate Sub Assembly	513985-03	513985-03	513985-03	513985-03
Pressure Plate	512860	512860	512860	512860	Pressure Plate	512860	512860	512860	512860
Flat Washer	000067*0042	000067*0042	000067*0042	000067*0042	Flat Washer	000067*0042	000067*0042	000067*0042	000067*0042
Locknut	000110*0075	000110*0075	000110*0075	000110*0075	Locknut	000110*0075	000110*0075	000110*0075	000110*0075
Cylinder	513988	513988	513988	513988	Cylinder	513988	513988	513988	513988
Lip Seal	000402*0005	000402*0005	000402*0005	000402*0005	Lip Seal	000402*0005	000402*0005	000402*0005	000402*0005
Lip Seal	000402*0006	000402*0006	000402*0006	000402*0006	Lip Seal	000402*0006	000402*0006	000402*0006	000402*0006
Gear	416538	416538	416538	416538	Gear	416538	416538	416538	416538
Wear Spacer	N/A	308397	308397	308397	Wear Spacer	N/A	308397	308397	308397
Reaction Plate Sub Assembly	N/A	513985-02	513985-02	513985-02	Reaction Plate Sub Assembly	N/A	513985-02	513985-02	513985-02
Reaction Plate	N/A	513989	513989	513989	Reaction Plate	N/A	513989	513989	513989
Pistion	512858	512858	512858	512858	Pistion	512858	512858	512858	512858
Release Spring	416751-01	416751-01	416751-01	416751-01	Release Spring	416751-01	416751-01	416751-01	416751-01
Inner Support Ring	414032-01	414032-01	414032-01	414032-01	Inner Support Ring	414032-01	414032-01	414032-01	414032-01
Outer Support Ring	414033-01	414033-01	414033-01	414033-01	Outer Support Ring	414033-01	414033-01	414033-01	414033-01
Flat Head Screw	000294*407	000294*407	000294*407	000294*407	Flat Head Screw	000294*407	000294*407	000294*407	000294*407
Pipe Plug	000077*0021	000077*0021	000077*0021	000077*0021	Pipe Plug	000077*0021	000077*0021	000077*0021	000077*0021
