Name Part No. Part No. Part No. Part No. Name Part No. Part No. Part No. Part No. Mounting Flange Sub Assembly. 513348-01 513348-01 513348-01 513348-01 Mounting Flange Sub Assembly. 513348-01 513348-01 513348-01 513348-01 Mounting Flange 513337 513337 513337 513337 Mounting Flange 513337 5...
| Name | Part No. | Part No. | Part No. | Part No. | Name | Part No. | Part No. | Part No. | Part No. |
| Mounting Flange Sub Assembly. | 513348-01 | 513348-01 | 513348-01 | 513348-01 | Mounting Flange Sub Assembly. | 513348-01 | 513348-01 | 513348-01 | 513348-01 |
| Mounting Flange | 513337 | 513337 | 513337 | 513337 | Mounting Flange | 513337 | 513337 | 513337 | 513337 |
| Wear Plate | 508459 | 508459 | 508459 | 508459 | Wear Plate | 508459 | 508459 | 508459 | 508459 |
| Stud | 000245*0069 | 000245*0069 | 000245*0069 | 000245*0069 | Stud | 000245*0069 | 000245*0069 | 000245*0069 | 000245*0069 |
| Friction Disc | 508725 | 508725 | 508725 | 508725 | Friction Disc | 508725 | 508725 | 508725 | 508725 |
| Friction Disc Core | 510745 | 510745 | 510745 | 510745 | Friction Disc Core | 510745 | 510745 | 510745 | 510745 |
| Clamp Tube | 306542-05 | 306542-20 | 306542-23 | 306542-24 | Clamp Tube | 306542-05 | 306542-20 | 306542-23 | 306542-24 |
| Pressure Plate Sub Assembly. | 513348-03 | 513348-03 | 513348-03 | 513348-03 | Pressure Plate Sub Assembly. | 513348-03 | 513348-03 | 513348-03 | 513348-03 |
| Pressure Plate | 513345 | 513345 | 513345 | 513345 | Pressure Plate | 513345 | 513345 | 513345 | 513345 |
| Flat Washer | 000153*0641 | 000153*0641 | 000153*0641 | 000153*0641 | Flat Washer | 000153*0641 | 000153*0641 | 000153*0641 | 000153*0641 |
| Locknut | 000110*0073 | 000110*0073 | 000110*0073 | 000110*0073 | Locknut | 000110*0073 | 000110*0073 | 000110*0073 | 000110*0073 |
| Cylinder | 513264 | 513264 | 513264 | 513264 | Cylinder | 513264 | 513264 | 513264 | 513264 |
| Lip Seal | 000402*0023 | 000402*0023 | 000402*0023 | 000402*0023 | Lip Seal | 000402*0023 | 000402*0023 | 000402*0023 | 000402*0023 |
| Lip Seal | 000402*0024 | 000402*0024 | 000402*0024 | 000402*0024 | Lip Seal | 000402*0024 | 000402*0024 | 000402*0024 | 000402*0024 |
| Gear | 411672 | 410970 | 412433 | 413195 | Gear | 411672 | 410970 | 412433 | 413195 |
| Wear Spacer | N/A | 308396 | 308396 | 308396 | Wear Spacer | N/A | 308396 | 308396 | 308396 |
| Reaction Plate Sub Assembly. | N/A | 513348-02 | 513348-02 | 513348-02 | Reaction Plate Sub Assembly. | N/A | 513348-02 | 513348-02 | 513348-02 |
| Reaction Plate | N/A | 513343 | 513343 | 513343 | Reaction Plate | N/A | 513343 | 513343 | 513343 |
| Pistion | 513317 | 513317 | 513317 | 513317 | Pistion | 513317 | 513317 | 513317 | 513317 |
| Release Spring | 416751-02 | 416751-02 | 416751-02 | 416751-02 | Release Spring | 416751-02 | 416751-02 | 416751-02 | 416751-02 |
| Inner Support Ring | 413107 | 413107 | 413107 | 413107 | Inner Support Ring | 413107 | 413107 | 413107 | 413107 |
| Outer Support Ring | 413108 | 413108 | 413108 | 413108 | Outer Support Ring | 413108 | 413108 | 413108 | 413108 |
| Flat Head Screw | 000294*407 | 000294*407 | 000294*407 | 000294*407 | Flat Head Screw | 000294*407 | 000294*407 | 000294*407 | 000294*407 |
| Pipe Plug | 000077*0021 | 000077*0021 | 000077*0021 | 000077*0021 | Pipe Plug | 000077*0021 | 000077*0021 | 000077*0021 | 000077*0021 |
| Name | Part No. | Part No. | Part No. | Part No. | Name | Part No. | Part No. | Part No. | Part No. |
| Mounting Flange Sub Assembly | 513985-01 | 513985-01 | 513985-01 | 513985-01 | Mounting Flange Sub Assembly | 513985-01 | 513985-01 | 513985-01 | 513985-01 |
| Mounting Flange | 513986 | 513986 | 513986 | 513986 | Mounting Flange | 513986 | 513986 | 513986 | 513986 |
| Wear Plate | 416527 | 416527 | 416527 | 416527 | Wear Plate | 416527 | 416527 | 416527 | 416527 |
| Stud | 307111-04 | 307111-10 | 307111-05 | 307111-07 | Stud | 307111-04 | 307111-10 | 307111-05 | 307111-07 |
| Friction Block Sub Assembly | 513990 | 513990 | 513990 | 513990 | Friction Block Sub Assembly | 513990 | 513990 | 513990 | 513990 |
| Friction Block | 513658 | 513658 | 513658 | 513658 | Friction Block | 513658 | 513658 | 513658 | 513658 |
| Friction Disc Core | 513667 | 513667 | 513667 | 513667 | Friction Disc Core | 513667 | 513667 | 513667 | 513667 |
| Clamp Tube | 308204-07 | 513985-03 | 308204-04 | 308204-05 | Clamp Tube | 308204-07 | 513985-03 | 308204-04 | 308204-05 |
| Pressure Plate Sub Assembly | 513985-03 | 513985-03 | 513985-03 | 513985-03 | Pressure Plate Sub Assembly | 513985-03 | 513985-03 | 513985-03 | 513985-03 |
| Pressure Plate | 512860 | 512860 | 512860 | 512860 | Pressure Plate | 512860 | 512860 | 512860 | 512860 |
| Flat Washer | 000067*0042 | 000067*0042 | 000067*0042 | 000067*0042 | Flat Washer | 000067*0042 | 000067*0042 | 000067*0042 | 000067*0042 |
| Locknut | 000110*0075 | 000110*0075 | 000110*0075 | 000110*0075 | Locknut | 000110*0075 | 000110*0075 | 000110*0075 | 000110*0075 |
| Cylinder | 513988 | 513988 | 513988 | 513988 | Cylinder | 513988 | 513988 | 513988 | 513988 |
| Lip Seal | 000402*0005 | 000402*0005 | 000402*0005 | 000402*0005 | Lip Seal | 000402*0005 | 000402*0005 | 000402*0005 | 000402*0005 |
| Lip Seal | 000402*0006 | 000402*0006 | 000402*0006 | 000402*0006 | Lip Seal | 000402*0006 | 000402*0006 | 000402*0006 | 000402*0006 |
| Gear | 416538 | 416538 | 416538 | 416538 | Gear | 416538 | 416538 | 416538 | 416538 |
| Wear Spacer | N/A | 308397 | 308397 | 308397 | Wear Spacer | N/A | 308397 | 308397 | 308397 |
| Reaction Plate Sub Assembly | N/A | 513985-02 | 513985-02 | 513985-02 | Reaction Plate Sub Assembly | N/A | 513985-02 | 513985-02 | 513985-02 |
| Reaction Plate | N/A | 513989 | 513989 | 513989 | Reaction Plate | N/A | 513989 | 513989 | 513989 |
| Pistion | 512858 | 512858 | 512858 | 512858 | Pistion | 512858 | 512858 | 512858 | 512858 |
| Release Spring | 416751-01 | 416751-01 | 416751-01 | 416751-01 | Release Spring | 416751-01 | 416751-01 | 416751-01 | 416751-01 |
| Inner Support Ring | 414032-01 | 414032-01 | 414032-01 | 414032-01 | Inner Support Ring | 414032-01 | 414032-01 | 414032-01 | 414032-01 |
| Outer Support Ring | 414033-01 | 414033-01 | 414033-01 | 414033-01 | Outer Support Ring | 414033-01 | 414033-01 | 414033-01 | 414033-01 |
| Flat Head Screw | 000294*407 | 000294*407 | 000294*407 | 000294*407 | Flat Head Screw | 000294*407 | 000294*407 | 000294*407 | 000294*407 |
| Pipe Plug | 000077*0021 | 000077*0021 | 000077*0021 | 000077*0021 | Pipe Plug | 000077*0021 | 000077*0021 | 000077*0021 | 000077*0021 |
